Electromagnetic Simulation Using the FDTD Method (eBook)

Dennis M. Sullivan (Autor)

eBook Download: PDF

2013 | 2. Auflage
192 Seiten
Wiley (Verlag)
978-1-118-64668-7 (ISBN)

Infos

A straightforward, easy-to-read introduction to the finite-difference time-domain (FDTD) method Finite-difference time-domain (FDTD) is one of the primary computational electrodynamics modeling techniques available. Since it is a time-domain method, FDTD solutions can cover a wide frequency range with a single simulation run and treat nonlinear material properties in a natural way. Written in a tutorial fashion, starting with the simplest programs and guiding the reader up from one-dimensional to the more complex, three-dimensional programs, this book provides a simple, yet comprehensive introduction to the most widely used method for electromagnetic simulation. This fully updated edition presents many new applications, including the FDTD method being used in the design and analysis of highly resonant radio frequency (RF) coils often used for MRI. Each chapter contains a concise explanation of an essential concept and instruction on its implementation into computer code. Projects that increase in complexity are included, ranging from simulations in free space to propagation in dispersive media. Additionally, the text offers downloadable MATLAB and C programming languages from the book support site (http://booksupport.wiley.com). Simple to read and classroom-tested, Electromagnetic Simulation Using the FDTD Method is a useful reference for practicing engineers as well as undergraduate and graduate engineering students.

Autor

DENNIS M. SULLIVAN is Professor of Electrical andComputer Engineering at the University of Idaho, Moscow. Anaward-winning author and researcher, he has done extensive work inseveral areas of simulation, including EM dosimetry, hyperthermiacancer treatment, nonlinear optics, and quantum semiconductors. In1997, Dr. Sullivan won the R. P. W. King Award from the IEEEAntennas and Propagation Society for the "Best Paper by a YoungInvestigator" for his paper "Z Transform Theory and FDTD Method."He is an IEEE Fellow, and is also the author of QuantumMechanics for Electrical Engineers, published by Wiley-IEEEPress.

Inhalt

Preface ix

Guide to the Book xi

1 One-Dimensional Simulation with the FDTD Method 1

1.1 One-Dimensional Free Space Simulation, 1

1.2 Stability and the FDTD Method, 5

1.3 The Absorbing Boundary Condition in One Dimension, 5

1.4 Propagation in a Dielectric Medium, 7

1.5 Simulating Different Sources, 8

1.6 Determining Cell Size, 10

1.7 Propagation in a Lossy Dielectric Medium, 10

1.A Appendix, 13

References, 14

2 More on One-Dimensional Simulation 21

2.1 Reformulation Using the Flux Density, 21

2.2 Calculating the Frequency Domain Output, 24

2.3 Frequency-Dependent Media, 27

2.3.1 Auxiliary Differential Equation Method, 30

2.4 Formulation Using Z Transforms, 32

2.4.1 Simulation of Unmagnetized Plasma, 33

2.5 Formulating a Lorentz Medium, 36

2.5.1 Simulation of Human Muscle Tissue, 39

References, 41

3 Two-Dimensional Simulation 53

3.1 FDTD in Two Dimensions, 53

3.2 The Perfectly Matched Layer (PML), 56

3.3 Total/Scattered Field Formulation, 65

3.3.1 A Plane Wave Impinging on a Dielectric Cylinder, 67

3.3.2 Fourier Analysis, 70

References, 71

4 Three-Dimensional Simulation 85

4.1 Free Space Simulation, 85

4.2 The PML in Three Dimensions, 89

4.3 Total/Scattered Field Formulation in Three Dimensions, 92

4.3.1 A Plane Wave Impinging on a Dielectric Sphere, 92

References, 96

5 Examples of Electromagnetic Simulation Using FDTD 113

5.1 Nonlinear Optical Pulse Simulation, 113

5.2 Finding the Eigenfunctions of a Two-Dimensional EM Cavity, 120

5.3 Simulation of RF Coils, 127

References, 136

6 Quantum Simulation 151

6.1 Simulation of the One-Dimensional, Time-Dependent Schrodinger Equation, 151

6.2 Tunneling, 156

6.3 Why Semiconductors Have Energy Bands, 157

References, 160

Appendix A The Z Transform 169

A.1 The Sampled Time Domain and the Z Transform, 169

A.1.1 Delay Property, 172

A.1.2 Convolution Property, 172

A.2 Examples, 174

A.3 Approximations in Going from the Fourier to the Z Domain, 176

References, 178

Index 179

Produkt-Details

• Erscheint lt. Verlag: 12.6.2013
• Sprache: englisch
• Themenwelt: Naturwissenschaften ► Physik / Astronomie ► Elektrodynamik
• Themenwelt: Technik ► Elektrotechnik / Energietechnik
• Schlagworte: Electrical & Electronics Engineering • Electromagnetic Compatibility • Electromagnetic theory • Elektromagnetische Verträglichkeit • Elektromagnetische Verträglichkeit • Elektromagnetismus • Elektrotechnik u. Elektronik • Materials Science • Materialwissenschaften • Materialwissenschaften / Theorie, Modellierung u. Simulation • Theory, Modeling & Simulation
• ISBN-10: 1-118-64668-1 / 1118646681
• ISBN-13: 978-1-118-64668-7 / 9781118646687
