Electromagnetic Simulation Using the FDTD Method (eBook)

Dennis M. Sullivan (Autor)

eBook Download: EPUB

2013 | 2. Auflage
192 Seiten
Wiley (Verlag)
978-1-118-64663-2 (ISBN)

Infos

A straightforward, easy-to-read introduction to the finite-difference time-domain (FDTD) method Finite-difference time-domain (FDTD) is one of the primary computational electrodynamics modeling techniques available. Since it is a time-domain method, FDTD solutions can cover a wide frequency range with a single simulation run and treat nonlinear material properties in a natural way. Written in a tutorial fashion, starting with the simplest programs and guiding the reader up from one-dimensional to the more complex, three-dimensional programs, this book provides a simple, yet comprehensive introduction to the most widely used method for electromagnetic simulation. This fully updated edition presents many new applications, including the FDTD method being used in the design and analysis of highly resonant radio frequency (RF) coils often used for MRI. Each chapter contains a concise explanation of an essential concept and instruction on its implementation into computer code. Projects that increase in complexity are included, ranging from simulations in free space to propagation in dispersive media. Additionally, the text offers downloadable MATLAB and C programming languages from the book support site (http://booksupport.wiley.com). Simple to read and classroom-tested, Electromagnetic Simulation Using the FDTD Method is a useful reference for practicing engineers as well as undergraduate and graduate engineering students.

Autor

DENNIS M. SULLIVAN is Professor of Electrical andComputer Engineering at the University of Idaho, Moscow. Anaward-winning author and researcher, he has done extensive work inseveral areas of simulation, including EM dosimetry, hyperthermiacancer treatment, nonlinear optics, and quantum semiconductors. In1997, Dr. Sullivan won the R. P. W. King Award from the IEEEAntennas and Propagation Society for the "Best Paper by a YoungInvestigator" for his paper "Z Transform Theory and FDTD Method."He is an IEEE Fellow, and is also the author of QuantumMechanics for Electrical Engineers, published by Wiley-IEEEPress.
