Practical Autodesk AutoCAD 2023 and AutoCAD LT 2023
Packt Publishing Limited (Verlag)
978-1-80181-646-5 (ISBN)
Learn techniques for making, modifying, and managing AutoCAD 2D and 3D drawings
Understand how to use reusable and named objects like blocks, xRef, and layers
Scale, annotate, and print drawings from model space and layout
Book DescriptionAutoCAD is one of the most versatile software applications for architectural and engineering designs and the most popular computer-aided design (CAD) platform for 2D drafting and 3D modeling. This hands-on 2nd edition guide will take you through everything you need to know to make the most out of this powerful tool, from a simple tour of the user interface to using advanced tools.
Starting with basic drawing shapes and functions, you'll get to grips with the fundamentals of CAD designs. You’ll then learn about effective drawing management using layers, dynamic blocks, and groups, and discover how to add annotations and plots like a professional. As you progress, the book will show you how to convert your 2D drawings into 3D models and shapes. You’ll also discover advanced features, such as isometric drawings, drawing utilities for managing and recovering complex files, quantity surveying, and multidisciplinary drawing files using xRefs. Finally, you’ll focus on rendering and visualizing your designs in AutoCAD.
By the end of this book, you’ll have developed a solid understanding of CAD principles and be able to work with AutoCAD software confidently to build impressive 2D and 3D creations.What you will learn
Understand CAD fundamentals like functions, navigation, and components
Create complex 3D objects using primitive shapes and editing tools
Work with reusable objects like blocks and collaborate using xRef
Explore advanced features like external references and dynamic blocks
Discover surface and mesh modeling tools such as Fillet, Trim, and Extend
Use the paper space layout to create plots for 2D and 3D models
Convert your 2D drawings into 3D models
Who this book is forThis 3D modeling book is for design engineers, mechanical engineers, architects, and anyone working in construction, manufacturing, or similar fields. Whether you’re an absolute beginner, student, or professional looking to upgrade your engineering design skills, you’ll find this AutoCAD book useful. No prior knowledge of CAD or AutoCAD is necessary.
Jaiprakash Pandey is a certified Autodesk AutoCAD professional and a member of the Autodesk Expert Elite community. He has worked in the design, manufacturing, and training industries and primarily delivers training to corporate clients. He has extensive experience in delivering CAD training to clients from Fortune 500 companies, design consulting firms, government organizations, and the military. Jaiprakash lives in India and has also created online courses and CAD training material for colleges and online portals. His articles have appeared in many CADand engineering-related publications. Yasser Shoukry is an engineering professional with a master's degree in mechanical engineering. He lives in Egypt and has more than 10 years of experience in different fields. He has worked in the construction industry as an MEP engineer, participated as a CFD technical analyst in automotive R&D and building smoke management projects, and worked on 3D modeling projects for oil and gas companies. The countless hours of drafting and modeling spent on all of these projects have given him extensive knowledge and experience in using AutoCAD. Moreover, he has great experience in AutoCAD training as he has successfully published training courses for AutoCAD on different online learning platforms.
Table of Contents
An Introduction to AutoCAD
Basic Drawing Tools and Commands
Learning about Modify Commands
Working with Arrays and Reusable Objects
Managing Drawings with Layers and Properties
Working with Hatches, Text, and Dimensions
Tables and Isometric Drawings
Customization Tools
External References and Dynamic Blocks
Introduction to 3D Modeling
Creating Primitive 3D Shapes
Conversion between 2D and 3D
Modifying 3D Objects
Paper Space Layouts and Printing
Rendering and Presentation
| Erscheinungsdatum | 31.10.2022 |
|---|---|
| Verlagsort | Birmingham |
| Sprache | englisch |
| Maße | 191 x 235 mm |
| Themenwelt | Informatik ► Weitere Themen ► CAD-Programme |
| ISBN-10 | 1-80181-646-8 / 1801816468 |
| ISBN-13 | 978-1-80181-646-5 / 9781801816465 |
| Zustand | Neuware |
