Introduction to casing design
Chapter outline head
1.1 Introduction 1
1.2 Design basics 2
1.3 Conventions used here 3
1.3.1 Organization of book 4
1.3.2 Units and math 4
Roundoff 5
1.3.3 Casing used in examples 5
1.4 Oilfield casing 6
1.4.1 Setting the standards 6
1.4.2 Manufacture of oilfield casing 6
Strength treatment of casing 8
1.4.3 Casing dimensions 9
Inside diameter and wall thickness 10
Joint length 10
1.4.4 Casing grades 12
API grades 12
1.4.5 Connections 14
Other threaded and coupled connections 15
1.4.6 Strengths of casing 17
1.4.7 Expandable casing 17
1.5 Closure 17
1.1 Introduction
In this textbook, we will explore the fundamentals and practices of basic casing design with some introduction to more advanced ideas and techniques. We will use a simple process that involves manual calculations and graphical plots. This is the historical method of learning casing design and will instill a depth of understanding. For the vast majority of casing strings run in the world this is still the method employed. Those engineers already well founded in the process may use more advanced techniques and specific software. While there is some excellent software on the market that does casing design, one cannot really learn the process using software. This is not by any means a harangue about casing design software; some of it is excellent and quite sophisticated especially compared to the crude first attempts that hit the market. But the unwelcome fact is that many who are using it are overwhelmed by multipage, detailed printouts, half of which they do not even pretend to understand. And truth be told, many of the “support” personnel experience the same problem. Information is not knowledge if you do not understand it.
1.2 Design basics
Casing design is a bit different from most structural design processes in engineering because the “structure” being designed is a single tubular monolith of given outside diameter primarily supported from the top end. There is nothing to actually “design” in the conventional sense of structural engineering. Geometrically speaking, our structure is already designed. The available tubular sizes and strengths are standardized, so the design process maybe thought of as a two-step process:
1. Calculate the anticipated loads.
2. Selecting from the available standard tubes those with adequate strength to safely sustain those loads.
As simple as that may sound, casing design is still not a linear process. It is not a matter of calculating the anticipated loads and then selecting the casing. The selected casing itself is part of the load. Hence, the process must be iterated to account for that fact. Still, it is quite an easy process in the vast majority of cases.
The basic design/selection sequence in its iterative form might be listed in steps:
1. Determine depths and sizes of casing.
2. Determine pressure loads.
3. Apply design factors and make preliminary selection.
4. Determine axial loads and apply design factors.
5. Adjust preliminary selection for axial design loads.
6. Adjust for combined tension/collapse loading.
Some might not consider Step 1 a part of casing design, and technically that is true. That step might be done by someone other than the casing designer and not in conjunction with the actual design process. However, we are going to include it in our treatment because it is essential for us to understand how it is done and how the results affect our design process.
The actual design process starts with Step 2, where we calculate the pressure loads for various scenarios using basic hydrostatics. We do this for all the strings in the well.
In Step 3 we select the worst case pressure loading from the previous step and apply a design factor which gives us a margin to account for uncertainty in the loads and pipe strengths. The results of that are design pressure-load plots for each string of casing in the well. From these plots, we make preliminary selections of casing, which will safely sustain those design loads.
Because the axial load (weight) of the string is a function of the casing itself, we must then calculate it from the preliminary pressure-load selection. We then apply a design factor to the axial load and check to see if our preliminary selection has sufficient axial strength. If it does, Step 4 is complete and we skip Step 5. If it does not, then in Step 5, we must modify the preliminary selection so that it also satisfies the axial design load. When we modify the preliminary selection, we must recalculate the axial load for the modified string and apply our axial design factor again. We must also check to ascertain that the modified string still meets our pressure-load design requirements. So in this step, the process becomes iterative. It is not difficult though, because in the manual process, it is easy to visually see the values and minimize the iterations. Seldom are more than two iterations required.
Finally, in Step 6, we check for the effects of combined axial tension and collapse loading, often referred to as biaxial loading. This is a critical step even in basic casing design, because tension in a string reduces the collapse resistance of the casing. This step too may require several iterations because any change or adjustment in the casing selection always requires that all the loads be rechecked.
For your early reference, Step 1 is covered in Chapter 2, Step 2 in Chapter 3, and Steps 3-6 in Chapter 4. Chapter 5 covers the casing installation process, and the remainder of the chapters covers more advanced topics.
1.3 Conventions used here
There is in the petroleum literature a virtual plethora of odd terminology, incoherent physical units, mathematical inconsistencies, and so forth. I have tried to adhere to several principles in this book:
• A readable text
• A progressive sequence for learning and self education
• Sufficient background material in appendices
• Adherence to ISO mathematics [1] and mechanics [2] standards
• Avoidance of acronyms except for organizational names (5) and those appearing in API/ISO standards (8) that you must necessarily understand plus only one other that is too common to not know (BOP)
Readability is essential for self-education, and I think, one of the most important features I have aimed for in this textbook. Perhaps I have oversimplified some concepts, but I prefer that to pedantic gibberish and superfluous acronyms that are more confusing than educational. And if the copy editor is successful at ironing out my convoluted sentence structure, you should find this book fairly readable.
1.3.1 Organization of book
The book is organized in a logical sequence that a beginner would follow to learn casing design, starting with the basics and proceeding to the more advanced topics. Chapters 2–4 illustrate basic casing design and Chapter 5 covers installation in the well. Having learned that material, the reader will have...
| Erscheint lt. Verlag | 4.6.2014 |
|---|---|
| Sprache | englisch |
| Themenwelt | Technik ► Bergbau |
| Technik ► Elektrotechnik / Energietechnik | |
| Technik ► Maschinenbau | |
| Technik ► Umwelttechnik / Biotechnologie | |
| Wirtschaft | |
| ISBN-10 | 0-12-800660-9 / 0128006609 |
| ISBN-13 | 978-0-12-800660-3 / 9780128006603 |
| Haben Sie eine Frage zum Produkt? |
PDF (Adobe DRM)Größe: 10,3 MB
Kopierschutz: Adobe-DRM
Adobe-DRM ist ein Kopierschutz, der das eBook vor Mißbrauch schützen soll. Dabei wird das eBook bereits beim Download auf Ihre persönliche Adobe-ID autorisiert. Lesen können Sie das eBook dann nur auf den Geräten, welche ebenfalls auf Ihre Adobe-ID registriert sind.
Details zum Adobe-DRM
Dateiformat: PDF (Portable Document Format)
Mit einem festen Seitenlayout eignet sich die PDF besonders für Fachbücher mit Spalten, Tabellen und Abbildungen. Eine PDF kann auf fast allen Geräten angezeigt werden, ist aber für kleine Displays (Smartphone, eReader) nur eingeschränkt geeignet.
Systemvoraussetzungen:
PC/Mac: Mit einem PC oder Mac können Sie dieses eBook lesen. Sie benötigen eine
eReader: Dieses eBook kann mit (fast) allen eBook-Readern gelesen werden. Mit dem amazon-Kindle ist es aber nicht kompatibel.
Smartphone/Tablet: Egal ob Apple oder Android, dieses eBook können Sie lesen. Sie benötigen eine
Geräteliste und zusätzliche Hinweise
Buying eBooks from abroad
For tax law reasons we can sell eBooks just within Germany and Switzerland. Regrettably we cannot fulfill eBook-orders from other countries.
EPUB (Adobe DRM)Größe: 12,4 MB
Kopierschutz: Adobe-DRM
Adobe-DRM ist ein Kopierschutz, der das eBook vor Mißbrauch schützen soll. Dabei wird das eBook bereits beim Download auf Ihre persönliche Adobe-ID autorisiert. Lesen können Sie das eBook dann nur auf den Geräten, welche ebenfalls auf Ihre Adobe-ID registriert sind.
Details zum Adobe-DRM
Dateiformat: EPUB (Electronic Publication)
EPUB ist ein offener Standard für eBooks und eignet sich besonders zur Darstellung von Belletristik und Sachbüchern. Der Fließtext wird dynamisch an die Display- und Schriftgröße angepasst. Auch für mobile Lesegeräte ist EPUB daher gut geeignet.
Systemvoraussetzungen:
PC/Mac: Mit einem PC oder Mac können Sie dieses eBook lesen. Sie benötigen eine
eReader: Dieses eBook kann mit (fast) allen eBook-Readern gelesen werden. Mit dem amazon-Kindle ist es aber nicht kompatibel.
Smartphone/Tablet: Egal ob Apple oder Android, dieses eBook können Sie lesen. Sie benötigen eine
Geräteliste und zusätzliche Hinweise
Buying eBooks from abroad
For tax law reasons we can sell eBooks just within Germany and Switzerland. Regrettably we cannot fulfill eBook-orders from other countries.
aus dem Bereich
