Multifunctional Antennas and Arrays for Wireless Communication Systems
Wiley-IEEE Press (Verlag)
978-1-119-53505-8 (ISBN)
Multifunctional Antennas and Arrays for Wireless Communication Systems is a comprehensive reference on state-of-the-art reconfigurable antennas and 4G/5G communication antennas. The book gives a unique perspective while giving a comprehensive overview of the following topics:
Frequency reconfigurable antennas
Pattern reconfigurable antennas
Polarization reconfigurable antennas
Reconfigurable antennas using Liquid Metal, Piezoelectric, and RF MEMS
MIMO and 4G/5G wireless communication antennas
Metamaterials and metasurfaces in reconfigurable antennas
Multifunctional antennas for user equipments (UEs)
Defense related antennas and applications
Flat panel phased array antennas
The book is a valuable resource for the practicing engineer as well as for those within the research field. As wireless communications continuously evolves, more and more functionally will be required, and thus multifunctional antennas and RF systems will be necessary. These multifunctional antennas will require a degree of reconfigurability, and this book discusses various methods which enable this. The main topics of frequency, pattern, and polarization reconfigurability is first discussed. Methods utilizing unique materials and devices, both real and artificial are discussed. The book also delves into 4G/5G antennas as it relates to MIMO, and millimeter-wave phased arrays. Finally, there is a section on defense related multifunctional RF antenna systems.
Satish K. Sharma, PhD, is a Professor in the Department of Electrical and Computer Engineering at the San Diego State University (SDSU), San Diego, California, USA. He is also Director of the Antenna and Microwave Laboratory (AML) at the SDSU. He served as the Associate Editor (AE) for the IEEE Transactions on Antennas and Propagation and is now serving as the AE for the IEEE Antennas and Wireless Propagation Letters. He is a Senior Member of the IEEE and URSI. Jia-Chi S. Chieh, PhD, has been working in the area of Antennas and RF Wireless Communications at the Naval Information Warfare Center in San Diego since 2004. He is also an Adjunct Faculty member at the SDSU with the Antenna and Microwave Laboratory (AML). Dr. Chieh has worked extensively in the area of phased array antennas over the past decade. He is a Senior Member of the IEEE.
