Antenna Design for Mobile Devices (eBook)

Zhijun Zhang (Autor)

eBook Download: PDF

2017 | 1. Auflage
320 Seiten
Wiley (Verlag)
978-1-119-13235-6 (ISBN)

Infos

Expanded and updated, this practical guide is a one-stop design reference containing all an engineer needs when designing antennas

• Integrates state-of-the-art technologies with a special section for step-by-step antenna design
• Features up-to-date bio-safety and electromagnetic compatibility regulation compliance and latest standards
• Newly updated with MIMO antenna design, measurements and requirements
• Accessible to readers of many levels, from introductory to specialist
• Written by a practicing expert who has hired and trained numerous engineers

Zhijun Zhang, Professor, Tsinghua University, Beijing, China. He holds rich industry experience, with senior positions as an antenna development engineer at Amphenol T&M Antennas, Nokia, and Apple, giving him a perspective of design practices at a number of different players in the mobile segment. Prior to Tsinghua, his academic career included a postdoctoral fellowship and research professorship at the University of Utah, and a position as Assistant Researcher at the University of Hawaii, where he continues to serve as Adjunct Professor. Zhang earned a B.S. in Microwave Engineering and an M.S. in Applied Physics at the University of Electronic Science and Technology of China, Chengdu. He holds a PhD in Electronic Engineering from Tsinghua University.
