Stress in ASME Pressure Vessels, Boilers, and Nuclear Components
Wiley-ASME Press (Verlag)
978-1-119-25928-2 (ISBN)
Stress in ASME Pressure Vessels, Boilers, and Nuclear Components offers a revised and updatededition of the text, Design of Plate and Shell Structures. This important resource offers engineers and students a text that covers the complexities involved in stress loads and design of plates and shell components in compliance with pressure vessel, boiler, and nuclear standards. The author covers the basic theories and includes a wealth of illustrative examples for the design of components that address the internal and external loads as well as other loads such as wind and dead loads.
The text keeps the various derivations relatively simple and the resulting equations are revised to a level so that they can be applied directly to real-world design problems. The many examples clearly show the level of analysis needed to achieve a safe design based on a given required degree of accuracy. Written to be both authoritative and accessible, this important updated book:
Offers an increased focus on mechanical engineering and contains more specific and practical code-related guidelines
Includes problems and solutions for course and professional training use
Examines the basic aspects of relevant theories and gives examples for the design of components
Contains various derivations that are kept relatively simple so that they can be applied directly to design problems
Written for professional mechanical engineers and students, this text offers a resource to the theories and applications that are needed to achieve an understanding of stress loads and design of plates and shell components in compliance with pressure vessel, boiler, and nuclear standards.
Maan H. Jawad, PhD, PE, ASME Life Fellow, is active on several technical committees of the American Society of Mechanical Engineers related to boilers and pressure vessels since 1972. He is President of his own engineering consulting firm and was formerly Director of Engineering of Nooter Corporation. He is the author of Guide to the Design of ASME Section VIII Pressure Vessels, now in its fourth edition.
