Building with Earth (eBook)

Design and Technology of a Sustainable Architecture

Gernot Minke (Autor)

eBook Download: PDF

2009 | 1., 2nd rev. ed..
199 Seiten
Birkhäuser Verlag GmbH
978-3-0346-1262-3 (ISBN)

Infos

Now in a second edition: This handbook offers a practical systematic overview of the many uses of rammed earth and techniques for processing it. Its properties and physical characteristics are described in informed and knowledgeable detail.

Prof. Dr.-Ing. Gernot Minke ist Hochschullehrer an der Universität Kassel, wo er das Forschungslabor für Experimentelles Bauen leitet und sich seit langem mit Entwicklungen des ökologischen Bauens beschäftigt. Mit dem Baustoff Lehm befaßt er sich in Theorie und Praxis seit 1977. Sein Buch «Building with Straw» ist ebenfalls bei Birkhäuser erschienen.

Autoren

lt;P>Prof. Dr.-Ing. Gernot Minke ist Hochschullehrer an der Universität Kassel, wo er das Forschungslabor für Experimentelles Bauen leitet und sich seit langem mit Entwicklungen des ökologischen Bauens beschäftigt. Mit dem Baustoff Lehm befaßt er sich in Theorie und Praxis seit 1977. Sein Buch «Building with Straw» ist ebenfalls bei Birkhäuser erschienen.

Prof. Dr. Gernot Minke is a professor at Universität Kassel, where he leads the Forschungslabor für Experimentelles Bauen. He has long concerned himself with developments in ecological building, and he has dealt with the building material clay in theory and practice since 1977. His book Building with Straw was also published by Birkhäuser.

Inhalt

Preface 7
I The technology of earth building 9
1 Introduction 11
History 11
Earth as a building material: the essentials 13
Improving indoor climate 15
Prejudices against earth as a building material 18
2 The properties of earth as a building material 19
Composition 19
Tests used to analyse the composition of loam 21
Effects of water 24
Effects of vapour 29
Influence of heat 31
Strength 32
pH-value 35
Radioactivity 35
Shelter against high-frequency electromagnetic radiation 35
3 Preparing of loam 36
Soaking, crushing and mixing 36
Sieving 38
Mechanical slurrying 38
Water curing 38
Thinning 38
4 Improving the earth’s characteristics by special treatment or additives 39
Reduction of shrinkage cracks 39
Stabilisation against water erosion 40
Enhancement of binding force 42
Increasing compressive strength 43
Strength against abrasion 47
Increasing thermal insulation 47
5 Rammed earthworks 52
Formwork 53
Tools 54
Method of construction 55
Shaping of openings 55
New wall construction techniques 56
Rammed earth domes 59
Drying 59
Labour input 60
Thermal insulation 60
Surface treatment 60
6 Working with earth blocks 61
History 61
Production of earth blocks 62
Material composition 65
Laying earth blocks 65
Surface treatment 66
Fixing fasteners to walls 67
Lightweight loam blocks 67
Special acoustic green bricks 68
7 Large blocks and prefabricated panels 69
Large blocks 69
Prefabricated wall panels 70
Floor slabs 70
Floor tiles 71
Extruded loam slabs 71
8 Direct forming with wet loam 72
Traditional wet loam techniques 72
The “Dünne loam loaf” technique 74
The stranglehm technique 75
9 Wet loam infill in skeleton structures 80
Thrown loam 80
Sprayed loam 80
Rolls and bottles of straw loam 81
Lightweight loam infill 82
Infill with stranglehm and earth-filled hoses 82
10 Tamped, poured or pumped lightweight loam 83
Formwork 83
Tamped lightweight straw loam walls 83
Tamped lightweight wood loam walls 84
Tamped, poured or pumped lightweight mineral loam walls 85
Pumped lightweight mineral loam floors 88
Loam-filled hollow blocks 89
Loam-filled hoses 90
11 Loam plasters 92
Preparation of ground 92
Composition of loam plaster 92
Guidelines for plastering earth walls 94
Sprayed plaster 95
Lightweight mineral loam plaster 95
Thrown plaster 95
Plastered straw bale houses 95
Wet formed plaster 96
Protection of corners 96
12 Weather protection of loam surfaces 98
Consolidating the surface 98
Paints 98
Making surfaces water-repellent 101
Lime plasters 101
Shingles, planks and other covers 103
Structural methods 103
13 Repair of loam components 104
The occurrence of damage in loam components 104
Repair of cracks and joints with loam fillers 104
Repair of cracks and joints with other fillers 105
Repairing larger areas of damage 105
Retrofitting thermal insulation with lightweight loam 106
14 Designs of particular building elements 107
Joints 107
Particular wall designs 108
Intermediate floors 110
Rammed earth floorings 112
Inclined roofs filled with lightweight loam 115
Earth-covered roofs 115
Earth block vaults and domes 117
Earthen storage wall in winter gardens 131
Loam in bathrooms 132
Built-in furniture and sanitary objects from loam 133
Wall heating systems 134
Passive solar wall heating system 134
15 Earthquake-resistant building 135
Structural measures 136
Openings for doors and windows 140
Bamboo-reinforced rammed earth walls 141
Domes 144
Vaults 145
Textile walls with loam infill 147
II Built examples 149
Residences 150
Two semi-deatched houses, Kassel, Germany 150
Residence cum office, Kassel, Germany 152
Residence at Phoenix, Arizona, USA 154
Farmhouse, Wazirpur, India 156
Honey house at Moab, Utah, USA 157
Residence, La Paz, Bolivia 158
Residence, Turku, Finland 159
Residence and studio at Gallina Canyon, New Mexico, USA 160
Residence at Villa de Leyva, Colombia 162
Low Compound at Scottsdale, Arizona, USA 164
Residence at Des Montes, near Taos, New Mexico, USA 166
Casita Nuaanarpoq at Taos, New Mexico, USA 168
Residence and office at Bowen Mountain, New South Wales, Australia 169
Vineyard residence at Mornington Peninsula, Victoria, Australia 170
Residence, Helensville, New Zealand 172
Residence, Sao Francisco Xavier, Brazil 174
Three-family house, Stein on the Rhine, Switzerland 176
Cultural, Educational and Sacral Buildings 177
School at Solvig, Järna, Sweden 177
Kindergarten, Sorsum, Germany 178
School in Rudrapur, Bangladesh 180
Kindergarten and nursery of Druk White Lotus School, Ladakh, India 182
Panafrican Institute for Development, Ouagadougou, Burkina Faso 184
Youth centre at Spandau, Berlin, Germany 186
Printing plant in Pielach, Austria 188
Office building, New Delhi, India 190
Mii amo spa at Sedona, Arizona, USA 192
Tourist resort at Baird Bay, Eyre Peninsula, South Australia 194
Charles Sturt University at Thurgoona, New South Wales, Australia 195
Chapel of the central clinic in Suhl, Germany 196
Cultural centre, La Paz, Bolivia 198
Mosque, Wabern, Germany 199
Chapel of Reconciliation, Berlin, Germany 200
Center of Gravity Foundation Hall at Jemez Springs, New Mexico, USA 202
Future prospects 204
Measures 205
Bibliographical references 206
Acknowledgements 207
Illustration credits 207

Produkt-Details

• Erscheint lt. Verlag: 1.2.2013
• Zusatzinfo: 496 b/w and 90 col. ill.
• Verlagsort: Basel/Berlin/Boston
• Sprache: englisch
• Themenwelt: Technik ► Architektur
• Schlagworte: Lehm • Lehmbau
• ISBN-10: 3-0346-1262-1 / 3034612621
• ISBN-13: 978-3-0346-1262-3 / 9783034612623
