Wide-band-gap semiconductors have been a research topic for many decades. However, it is only in recent years that the promise for technological applications came to be realized; simultaneously an upsurge of experimental and theoretical activity in the field has been witnessed. Semiconductors with wide band gaps exhibit unique electronic and optical properties. Their low intrinsic carrier concentrations and high breakdown voltage allow high-temperature and high-power applications (diamond, SiC etc.). The short wavelength of band-to-band transitions allows emission in the green, blue, or even UV region of the spectrum (ZnSe, GaN, etc.). In addition, many of these materials have favorable mechanical and thermal characteristics.

These proceedings reflect the exciting progress made in this field. Successful p-type doping of ZnSe has recently led to the fabrication of blue-green injection lasers in ZnSe; applications of short-wavelength light-emitting devices range from color displays to optical storage. In SiC, advances in growth techniques for bulk as well as epitaxial material have made the commercial production of high-temperature and high-frequency devices possible. For GaN, refinement of growth procedures and new ways of obtaining doped material have resulted in blue-light-emitting diodes and opened the road to the development of laser diodes. Finally, while the quality of artificial diamond is not yet high enough for electronic applications, the promise it holds in terms of unique material properties is encouraging intense activity in the field.

This volume contains contributions from recognized experts presently working on different material systems in the field. The papers cover the theoretical, experimental and application-oriented aspects of this exciting topic.

Textauszug

Thin films and devices of diamond, silicon carbide and gallium nitride

Robert F. Davis ,     Department of Materials Science and Engineering, North Carolina State University, Raleigh, NC, USA

 Robert F. Davis, Department of Materials Science and Engineering, North Carolina State University, Raleigh, NC 27607, USA.

The extreme properties of diamond, SiC and GaN provide combinations of attributes for high-power, -temperature, -frequency and optoelectronic applications. The methods of deposition, the results of chemical, structural, microstructural and electrical characterization and device development are reviewed for thin films of these three materials. Problems and areas of future research are also noted.

1 Introduction

The principal driving force for the current resurgence in interest in diamond (C), SiC and GaN (as well as cubic-BN, AlN, InN and alloys of these materials) is their potential as high-power, high-temperature microelectronic and/or optoelectronic devices resistant to radiation damage.

Johnson [1] has argued that the basic limitation on the high frequency and high power capabilities of selected discrete transistor devices is set by the product of the breakdown electric field, EB, and the saturated (limiting) electron velocity, Vs, i.e. the velocity at which an electron has enough energy to emit an optical phonon. Johnson’s figures of merit (EBVS/π)2 for selected semiconductors and their associated ratios to those for silicon are presented in table 1.

Table 1

Johnson’s figure of merit for a transistor’s power and frequency performance for selected semiconductor materials.

Keyes [2] has considered the switching speed of transistors in integrated circuits for computer logic applications. In this case a high limiting velocity allows high speed devices. A problem of small, closely spaced devices is the very high density of power dissipation, i.e. the production of heat. The heat flows from the device by conduction through the semiconductor material thereby encountering a thermal resistance that is inversely proportional to the size of the device. A lower limit is set on the device size by the maximum permissible thermal resistance and, thus, a high thermal conductivity, σT, is highly desirable in the device material. An additional set of figures of merit which includes Vs, σT and the dielectric constant K has been developed by Keyes [2] and is shown in table 2.

Table 2

Keyes’ figure of merit for the speed of a transistor for selected semiconductors.

Finally GaN and SiC are also of interest as light-emitting devices and for other optical applications. Important optical device applications for the nitrides include semiconductor lasers, light-emitting diodes (LEDs) and optical detectors. Although band-to-band transitions in SiC occur indirectly via intermediate energy levels in the conduction band and thus negate the possibility of laser applications, doping of the material with various donor and acceptor species allows electroluminescent devices to be produced. The creation of an abrupt p(aluminium doped)-n(nitrogen doped) junction in the α(6H)–SiC polytype (see discussion of polytypism in SiC in section 3) also allows the fabrication of blue LEDs in this form of SiC.

The following sections present an overview of the results and conclusions of recent materials research on diamond (diamond-like materials are not discussed), SiC and GaN as they pertain to microelectronics and optoelectronics, as well as a description of problems encountered and suggestions for future directions for research to overcome these problems.

2 Diamond

2.1 Background

The free energy difference between metastable diamond and stable graphite is only 453 cal/mol [3] at 1 atm. Thus the rarity of diamond is surprising when one considers that this is less than RT (≈600cal/mol) at room temperature. There are several reasons for the uncommon occurrence of diamond. Firstly, the kinetics of graphite formation are considerably faster than those of diamond, as would be predicted by the large activation energy barrier between these two materials [4]. Secondly, the entropy of diamond is less than the entropy of graphite by 0.78 cal/K mol [3]. Finally, a large activation energy barrier exists between graphite and diamond which prevents even small particles from forming at room temperature under equilibrium conditions. The density of diamond (3.51 g/cm3) is significantly greater than the density of graphite (2.25 g/cm3); thus, the former becomes the equilibrium form of C only at high pressure.

The breakthrough in the low-pressure synthesis of diamond was mainly a result of research by Soviet scientists in the late 1970s and early 1980s which indicated that gas activation techniques could greatly increase the growth rate of diamond while suppressing the graphite deposition. The results of these efforts clearly demonstrated that a concentration of atomic hydrogen, exceeding that of the equilibrium concentration associated with the thermal disassociation of the reactant hydrocarbon gas(es), was necessary to achieve diamond growth [5]. The flow of the hydrocarbon gas and hydrogen could now be simultaneous. In 1977, Derjaguin and Fedoseev [6] described three approaches to produce higher concentrations of atomic hydrogen than obtained previously: catalytic, electrical discharge and via heated tungsten filament. The significant results of this research were not published in English until 1981 [7] with additional details in 1984 [8]. This was followed by intensive efforts throughout the 1980s at the National Institute for Research in Inorganic Materials in Japan. This research quickly resulted in numerous publications [9–15] containing scanning electron micrographs of highly faceted, thick continuous films, confirming electron diffraction results and a host of spectroscopic data which removed all doubt that diamond films containing very small amounts of graphite could be grown at reasonable rates under highly metastable conditions on a variety of substrates, including Si, SiC, WC, Ta, W, Si3N4, Cu, Ni, Mo, BN, SiO2, Ti, Hf, Nb and Al2O3. This work also resulted in several new techniques for gas activation and diamond deposition. These have been grouped into five major categories [16]: (i) thermally activated chemical vapor deposition (CVD); (ii) high-frequency plasma enhanced CVD; (iii) direct-current (DC) discharge assisted CVD; (iv) combustion flame; and (v) hybrids of these and others. Only (i), (ii) and (iii) are considered likely to result in films suitable for electronic applications. Common to all techniques is the production of a high supersaturation of atomic H with a supersaturation of carbonic species and a substrate temperature in the range of 975–1275 K. Other similarities include process parameters of gas pressure (∼0.1 atm), the percentage of hydrogen in the gas phase (∼95–99.9%) and the resulting film morphology.

2.2 Nucleation and growth

2.2.1 The role of atomic hydrogen

One of the most important aspects of any discussion of the mechanisms and theory of diamond growth from the vapor phase is the role of atomic H. Firstly, within all the successful growth schemes which use H2 and a C-containing gas mixture for vapor phase deposition. The CH4 (or other hydrocarbon) and H2 are excited and dissociate into atomic H, hydrocarbon radicals and, in the case of plasma deposition, ions. The hydrocarbon species then adsorb onto the surface of the substrate and begin to grow via various hydrogen releasing reactions. These clusters may contain single, double or triple bonded carbons. However, the supersaturation of atomic H rapidly attacks all but the sp3 bonded diamond component. This may help to maintain sp3 bonding in this phase and thus reduce the amount of graphitic or amorphous C which deposits on the substrate.

Atomic H may also play a variety of other important roles in the deposition of diamond. Diamond bonds are all single bonds; graphite contains both single and double bonds. The dangling bonds on the surface of diamond are energetically unstable, and the cleaved surface will soon reconstruct to a ‘graphite-like’ surface containing a mixture of single and double bonds to reduce the surface energy. A monolayer of reacted atomic H bonded to the single bonds of diamond will prevent the reconstruction. However, because the H-C bond is stronger than the C-C bond, no diamond growth can occur, unless a bound H atom can be displaced from the surface.

The continuous exposure of the H-terminated surface to the incoming atomic H provides an escape from the no-growth situation just noted by providing vacant sites created by the reaction between the bonded and gas phase atomic H species. Because the H–H bond is stronger than the H-C bond, this is an exothermic event. In most CVD diamond growth, the ratio of H2 to C is ∼50:1 [17]. Thus the most probable next event is that another H will fill a vacant site. However, occasionally, a C-containing species will interact with the vacant site...
