Electrostatic Discharge

Kenneth L. Kaiser (Autor)

Buch | Hardcover

344 Seiten

2005
Crc Press Inc (Verlag)
978-0-8493-7188-2 (ISBN)

Artikel merken

Demystifies electrostatic discharge and explains the source and limitations of the approximations, guidelines, models, and rules-of-thumb used in this field. This book includes numerous examples and uses Mathcad to generate all of the figures and many solutions to equations.

In chapters culled from the popular and critically acclaimed Electromagnetic Compatibility Handbook, Electrostatic Discharge provides a tightly focused, convenient, and affordable reference for those interested primarily in this subset of topics. Author Kenneth L. Kaiser demystifies electrostatic discharge and explains the source and limitations of the approximations, guidelines, models, and rules-of-thumb used in this field. The material is presented in a unique question-and-answer format that gets straight to the heart of each topic. The book includes numerous examples and uses Mathcad to generate all of the figures and many solutions to equations. In many cases, the entire Mathcad program is provided.

Kaiser, Kenneth L.

AIR BREAKDOWN: Breakdown Voltage. Glows, Arcs, Coronas, and Sparks. Nonuniform Fields and Time-Varying Arc. Ideal Switching of Simple Loads. Ideal Switching of Complex Loads. Switching and Breakdown. Showering Arc. Speed of Switching. Suppressing the Breakdown. Switch Network Example. Arc Suppression with Resistive Loads. Arc Suppression with Capacitive Loads. Arc Suppression with Inductive Loads. Sparking at Very Low Voltages?. Switch Corrosion and Erosion. Maximum Electric Field and Breakdown Table. Minimum Corona Voltage. Voltage Rating of Coax. Solutions to Poisson's Equation. Arcing in a Silo. All of the Electric Field Boundary Conditions. Powder Bed. The Field from Corona. ELECTROSTATIC DISCHARGE: What is ESD?. Methods of Charging. Triboelectric Series. Microphone. Voltage and Current Responses. Sources of Current. Rate of Charge Decay. Maximum Surface Charge Before Breakdown. Grounded Conducting Objects and Charged Insulating Surfaces. Charge Accumulation Along Interfaces. Convection Charge Flow. Potential of an Insulator's Surface . Electric Field from Simple Charge Distributions. Electric Field From Other Charge Distributions. Discharges Classified. Minimum Ignition Energy. Electrostatic Hazard Case Studies. Measuring the Electric Field. Measuring Voltage. Measuring Bulk and Surface Resistivity. Maximum Body Voltage and Typical Capacitances. RLC Discharge Model. ESD Rules-of-Thumb and Guidelines. Raindrop Bursts, P-Static, and Corona Noise. Locating Weaknesses with a "Zapper. Surround, Ground, and Impound. Wrist and Ankle Straps. Floor Coatings. Pink, Black, and Shielded Bags. Static-Dissipative Work Surfaces. Sugar Charge Decay. Capacitance Measurement for Multiple Conductors. Energy and Capacitance. Capacitance Formula.

Erscheint lt. Verlag	22.9.2005
Verlagsort	Bosa Roca
Sprache	englisch
Maße	178 x 254 mm
Gewicht	771 g
Themenwelt	Naturwissenschaften ► Physik / Astronomie ► Elektrodynamik
ISBN-10	0-8493-7188-0 / 0849371880
ISBN-13	978-0-8493-7188-2 / 9780849371882
Zustand	Neuware
