Petroleum Refining Design and Applications Handbook, Volume 4
Wiley-Scrivener (Verlag)
978-1-119-82752-8 (ISBN)
- Titel ist leider vergriffen;
keine Neuauflage - Artikel merken
This book provides the design of heat exchanger equipment, crude oil fouling in pre-heat train exchangers, crude oil fouling models, fouling mitigation and monitoring, prevention and control of liquid and gas side fouling, using the Excel spreadsheet and UniSim design software for the design of shell and tube heat exchangers, double pipe heat exchangers, air-cooled exchangers, heat loss tracing for process piping, pinch analysis for hot and cold utility targets and process safety incidents involving these equipment items and pertinent industrial case studies.
Use of UniSim Design (UniSim STE) software is illustrated in further elucidation of the design of shell and tube heat exchangers, condensers, and UniSim ExchangerNet R470 for the design of heat exchanger networks using pinch analysis. This is important for determining minimum cold and hot utility requirements, composite curves of hot and cold streams, the grand composite curve, the heat exchanger network, and the relationship between operating cost index target and the capital cost index target against ΔTmin.
Useful as a textbook, this is also an excellent, handy go-to reference for the veteran engineer, a volume no chemical or process engineering library should be without. Written by one of the world’s foremost authorities, this book sets the standard for the industry and is an integral part of the petroleum refining renaissance. It is truly a must-have for any practicing engineer or student in this area.
This groundbreaking new volume:
Assists engineers in rapidly analyzing problems and finding effective design methods and select mechanical specifications
Provides improved design manuals to methods and proven fundamentals of process design with related data and charts
Covers a complete range of basic day–to–day petroleum refining operations topics with new materials on significant industry changes
Extensive Excel spreadsheets for the design of process vessels for mechanical separation of two-phase and three-phase fluids, double-pipe heat exchanger, air-cooled exchanger, pinch analysis for hot and cold utility targets.
Provides UniSim ®-based case studies for enabling simulation of key processes outlined in the book
Helps achieve optimum operations and process conditions and shows how to translate design fundamentals into mechanical equipment specifications
Has a related website that includes computer applications along with spreadsheets and concise applied process design flow charts and process data sheets
Provides various case studies of process safety incidents in refineries and means of mitigating these from investigations by the US Chemical Safety Board
Includes a vast Glossary of Petroleum and Technical Terminology
Kayode Coker PhD, is Engineering Consultant for AKC Technology, an Honorary Research Fellow at the University of Wolverhampton, U.K., a former Engineering Coordinator at Saudi Aramco Shell Refinery Company and Chairman of the department of Chemical Engineering Technology at Jubail Industrial College, Saudi Arabia. He has been a chartered chemical engineer for more than 30 years. He is a Fellow of the Institution of Chemical Engineers, U.K. and a senior member of the American Institute of Chemical Engineers. He holds a B.Sc. honors degree in Chemical Engineering, a Master of Science degree in Process Analysis and Development and Ph.D. in Chemical Engineering, all from Aston University, Birmingham, U.K. and a Teacher’s Certificate in Education at the University of London, U.K. He has directed and conducted short courses extensively throughout the world and has been a lecturer at the university level. His articles have been published in several international journals. He is an author of five books in chemical engineering, a contributor to the Encyclopedia of Chemical Processing and Design. Vol 61. He was named as one of the International Biographical Centre’s Leading Engineers of the World for 2008. Also, he is a member of International Who’s Who of ProfessionalsTM and Madison Who’s Who in the U.S.
