Dynamic Thermal characterization of Thin Films via IR Thermography
Seiten
2018
Verein zur Förderung des Walter Schottky Instituts der Technischen Universität München (Verlag)
978-3-946379-15-7 (ISBN)
Verein zur Förderung des Walter Schottky Instituts der Technischen Universität München (Verlag)
978-3-946379-15-7 (ISBN)
- Keine Verlagsinformationen verfügbar
- Artikel merken
This work presents a novel method for the thermal characterization of thin films via infrared thermography. In order to measure the thermal conductivity of a material, a temperature gradient has to be introduced. For this purpose, the films are suspended above rectangular and circular cavities in opaque substrates. The free-standing area of the films is heated homogeneously by a visible light source. In order to measure the resulting temperature distribution, a contact-free method is preferred, such as infrared microscopy. Under steady-state conditions, the measured temperature distribution can be fitted with an analytical model, yielding the in-plane thermal conductivity. The method can be extended by periodically heating the film and capturing the temperature distribution as a function of time. We develop a finite differences model with which not only the thermal conductivity but also the volumetric heat capacity and the effective total emissivity can be obtained from the time-dependent temperature measurement.
Erscheinungsdatum | 20.11.2018 |
---|---|
Verlagsort | Garching |
Sprache | englisch |
Maße | 150 x 210 mm |
Themenwelt | Naturwissenschaften ► Physik / Astronomie ► Allgemeines / Lexika |
Schlagworte | ir thermography • thermal conductivity • Thin Films |
ISBN-10 | 3-946379-15-X / 394637915X |
ISBN-13 | 978-3-946379-15-7 / 9783946379157 |
Zustand | Neuware |
