Recycling of Lithium-Ion Batteries (eBook)

The LithoRec Way

Arno Kwade, Jan Diekmann (Herausgeber)

eBook Download: PDF

2017 | 1st ed. 2018
XXXIII, 288 Seiten
Springer International Publishing (Verlag)
978-3-319-70572-9 (ISBN)

Infos

This book addresses recycling technologies for many of the valuable and scarce materials from spent lithium-ion batteries. A successful transition to electric mobility will result in large volumes of these.
The book discusses engineering issues in the entire process chain from disassembly over mechanical conditioning to chemical treatment. A framework for environmental and economic evaluation is presented and recommendations for researchers as well as for potential operators are derived.
