Vehicle Suspension Systems and Electromagnetic Dampers (eBook)

Saad Kashem, Romesh Nagarajah, Mehran Ektesabi (Autoren)

eBook Download: PDF

2017 | 1st ed. 2018
XXI, 205 Seiten
Springer Singapore (Verlag)
978-981-10-5478-5 (ISBN)

Infos

 This book describes the development of a new analytical, full-vehicle model with nine degrees of freedom, which uses the new modified skyhook strategy (SKDT) to control the full-vehicle vibration problem. The book addresses the incorporation of road bank angle to create a zero steady-state torque requirement when designing the direct tilt control and the dynamic model of the full car model. It also highlights the potential of the SKDT suspension system to improve cornering performance and paves the way for future work on the vehicle's integrated chassis control system. Active tilting technology to improve vehicle cornering is the focus of numerous ongoing research projects, but these don't consider the effect of road bank angle in the control system design or in the dynamic model of the tilting standard passenger vehicles. The non-incorporation of road bank angle creates a non-zero steady state torque requirement.

Dr. Saad Kashem received his Ph.D. from Swinburne University of Technology (SUT), Melbourne, Australia, in 2013. He received his BSc in Electrical and Electronic Engineering from East West University, Dhaka, Bangladesh, in 2009. At present, he is with Faculty of Engineering, Computing and Science in Swinburne University of Technology Sarawakak . Dr. Saad has over six years experience in both industry and academia. His major areas of expertise and research are Vehicle dynamic, Electric vehicle, Renewable Energy Systems, Intelligent and Autonomous Control, Robotics, Nonlinear control theory and applications. He is a Professional Member of Institution of Engineering and Technology, UK (IET), Institute of Electrical and Electronic Engineers (IEEE); IEEE Robotics and Automation Society; and International Association of Engineers (IAENG). He is editor & reviewer of many national & international reputed Journals & Conferences.

Professor Romesh Nagarajah is the Pro

fessor of Mechanical Engineering at Swinburne University of Technology. He has an Honours degree in Mechanical Engineering and Masters and Doctoral degrees in Robotics and Flexible Manufacturing Systems respectively. Professor Nagarajah has over forty years experience in both industry and academia. His current research is in the development of intelligent robot and inspection systems for a variety of applications. Over the last twenty years he has worked in collaboration with several aerospace, automotive and automotive supplier companies in developing smart inspection systems that combine a variety of sensor technologies with artificial intelligence techniques to inspect products and processes. Professor Nagarajah and members of his research group have several international patents. He has been awarded several research grants by the Australian Research Council and various Co-operative Research Centres. Professor Nagarajah is on the editorial board of the International Journal of Advanced Manufacturing Technology and has provided consultancy services to various companies in the automotive, aerospace, defence and food
manufacturing sectors.

Mehran Ektesabi has completed his Bachelor degree (1982), his Master degree (1984) and his Ph.D. (1989) all in Electrical Engineering. He has more than 30 years experience in design & development of control and drive systems. He has two international patents in the field of Motor Control and winner of many national & international awards. At present, he is with Faculty of Engineering and Industrial Sciences, in Swinburne University of Technology, Australia. He is an active member of IEEE, founder Chair of IEEE Vehicular Technology Society (VTS) Victorian Chapter and Consular of IEEE branch in Swinburne. He is executive editor, editor & reviewer of many national & international reputed Journals & Conferences. His major areas of expertise and research are Power Electronics, Electric Motor Control Systems, Power Quality Controllers, Energy Saving and Compatibility, Renewable Energy Systems, Intelligent and Autonomous Control, Soft Computing Adaptive Control and System Identification.

Inhalt

Author´s Declaration 6
Acknowledgements 7
Abstract 8
Contents 10
List of Figures 11
List of Tables 18
Chapter 1: Introduction 19
1.1 Background 19
1.2 Motivation and Methodologies 23
1.3 Outline 25
Chapter 2: Control Strategies in the Design of Automotive Suspension Systems 27
2.1 Control Strategies 27
2.1.1 Linear Quadratic Regulator and Linear Quadratic Gaussian 28
2.1.2 Sliding Mode Control 30
2.1.3 Fuzzy and Neuro-Fuzzy Control 31
2.1.4 Skyhook Control Method 32
2.1.5 Groundhook Control Method 34
2.2 Active Tilting Technology 35
2.2.1 Narrow Titling Road Vehicle 35
2.2.2 Tilting Standard Production Vehicle 38
2.3 Conclusion 40
Chapter 3: Vehicle Suspension System 41
3.1 Vehicle Suspension System 41
3.1.1 Passive Suspension System 41
3.1.2 Semi-active Suspension System 43
3.1.3 Active Suspension System 44
3.2 Quarter-Car Suspension Model 45
3.2.1 Explanation of Motion Equations of Quarter-Car 46
3.2.2 High- Versus Low-Bandwidth Suspension System 50
3.3 Comparison of Recent Models 51
3.4 Conclusions 54
Chapter 4: Design of Semi-active Suspension System 56
4.1 Semi-active Control Algorithms 56
4.1.1 Continuous Skyhook Control of Karnopp et al. [14] 56
4.1.2 Modified Skyhook Control of Bessinger et al. [15] 57
4.1.3 Optimal Skyhook Control of Nguyen et al. [51] 58
4.1.4 Proposed Skyhook Control with Adaptive Skyhook Gain 58
4.2 Road Profile Description 61
4.3 Comparison and Evaluation Using Y. Chens´ Model 63
4.3.1 Comparison 64
4.3.1.1 Comparison of Ride Comforts Performance 64
4.3.1.2 Comparison on Road Handling Performance 65
4.3.2 Evaluation 66
4.3.2.1 Human Vibration Sensitivity 66
4.3.2.2 Admissible Acceleration Levels Test Based on ISO 2631 67
4.4 Comparison and Evaluation of Quanser Suspension Plant 68
4.4.1 Quanser Quarter-Car Suspension Plant 68
4.4.1.1 State-Space Representation 68
4.4.1.2 Experimental Setup 72
4.4.1.3 Comparison of Ride Comfort Performance 74
4.4.1.4 Comparison on Road-Handling Performance 74
4.4.1.5 Human Vibration Sensitivity 76
4.4.1.6 Admissible Acceleration Levels Test Based on ISO 2631 76
4.5 Conclusions 80
Chapter 5: Full Car Model Cornering Performance 81
5.1 Full Car Modelling 81
5.1.1 Semi-active Suspension Model 81
5.1.2 Vehicle Tilting Model 83
5.2 Vehicle Rollover Estimation 85
5.3 Controller Design 86
5.3.1 Direct Tilt Control Design 86
5.3.1.1 Desired Tilting Angle 86
5.3.1.2 Desired Actuator Force 87
5.3.1.3 Actuator Selection 88
5.4 Road Profile and Driving Scenario 89
5.4.1 Driving Scenario One 89
5.4.2 Driving Scenario Two 89
5.4.3 Driving Scenario Three 90
5.4.4 Driving Scenario Four 91
5.5 Evaluation Criteria 91
5.5.1 Evaluation of Ride Comfort Performance 92
5.5.2 Admissible Acceleration Level Test Based on ISO 2631 92
5.5.3 Evaluation of Road Handling Performance 93
5.6 Conclusion 93
Chapter 6: Simulation of Full Car Model 94
6.1 Simulation Environment 94
6.2 Simulation with the Proposed Skyhook Controller 95
6.2.1 Simulation on Road Class A 95
6.2.1.1 Simulations of Ride Comfort in the Frequency Domain 97
6.2.1.2 Simulations of Ride Comfort in the Time Domain 99
6.2.2 Simulation on Road Class B 101
6.2.2.1 Simulations of Ride Comfort in the Frequency Domain 101
6.2.2.2 Simulations of Ride Comfort in the Time Domain 102
6.2.3 Simulation on Road Class C 104
6.2.3.1 Simulations of Ride Comfort in the Frequency Domain 105
6.2.3.2 Simulations of Ride Comfort in the Time Domain 106
6.2.4 Simulation on Combined Road 108
6.2.4.1 Simulations of Ride Comfort in the Frequency Domain 108
6.2.4.2 Simulations of Ride Comfort in the Time Domain 110
6.3 Simulation with Skyhook and Direct Tilt Controller 112
6.3.1 Simulation on Driving Scenario One 113
6.3.2 Simulation on Driving Scenario Two 116
6.3.3 Simulation on Driving Scenario Three 119
6.3.4 Simulation on Driving Scenario Four 121
6.4 Simulation Summary 123
6.4.1 Simulations of Ride Comfort in the Frequency Domain 124
6.4.2 Simulations of Ride Comfort in the Time Domain 126
6.5 Conclusions 130
Chapter 7: Experimental Analysis of Full Car Model 158
7.1 Experimental Environment 158
7.2 Quanser Plant at Front Left Suspension 160
7.2.1 Experiments of Ride Comfort in the Frequency Domain 162
7.2.2 Experiments of Ride Comfort in the Time Domain 164
7.3 Quanser Plant at Rear Right Suspension 168
7.3.1 Experiments of Ride Comfort in the Frequency Domain 169
7.3.2 Experiments of Ride Comfort in the Time Domain 172
7.4 Conclusions 176
Chapter 8: Conclusions and Recommendations 186
8.1 Introduction 186
8.2 Overview of the Study 187
8.3 Recommendations for Future Study 190
Appendix A 191
Simulink Model 191
Appendix B 193
MATLAB Code for Frequency Domain Analysis of Full Car Model 193
Appendix C 200
MATLAB Code for Time Domain Analysis of Full Car Model 200
References 212

Produkt-Details

• Erscheint lt. Verlag: 4.9.2017
• Reihe/Serie: Springer Tracts in Mechanical Engineering
• Reihe/Serie: Springer Tracts in Mechanical Engineering
• Zusatzinfo: XXI, 205 p. 130 illus., 128 illus. in color.
• Verlagsort: Singapore
• Sprache: englisch
• Themenwelt: Naturwissenschaften ► Physik / Astronomie ► Strömungsmechanik
• Themenwelt: Technik ► Bauwesen
• Themenwelt: Technik ► Fahrzeugbau / Schiffbau
• Themenwelt: Technik ► Maschinenbau
• Schlagworte: Active Tilt System • Analytical Vehicle Model • automotive engineering • Direct Tilt Control • fluid- and aerodynamics • Modified Skyhook Strategy (SKDT) • Quanser Simulink Model • Semi-active Suspension • Smart Suspension • Vehicle Dynamics • Vehicle Vibration Control
• ISBN-10: 981-10-5478-9 / 9811054789
• ISBN-13: 978-981-10-5478-5 / 9789811054785
