Nonimaging Fresnel Lenses

Design and Performance of Solar Concentrators

Ralf Leutz, Akio Suzuki (Autoren)

Buch | Hardcover

XI, 274 Seiten

2001 | 2001
Springer Berlin (Verlag)
978-3-540-41841-2 (ISBN)

Lese- und Medienproben

Blick ins Buch (midvox)

Artikel merken

Nonimaging Fresnel Lenses: Design and Performance of Solar Concentmtors; what are we talking about? It is easy to forget that you, dear reader, may not be one of those who work inexactly the same field as we do: nonimaging optics for the concentration of sunlight. You may be a researcher in some optical science interested in the core subject of this book: the world's first practical design of a nonimaging Fresnel lens concentrator. You may not be too excited about the collection of solar energy, but you would want a fuB description of the optical performance of the lens. Which you will get, mostly in terms of nonimaging optics, complete with test results, and set against the competition of imaging Fresnel lenses and mirror-based imaging and nonimaging concentrators. If you are a solar energy professional, you are likely to be interested in reading why nonimaging optics and solar energy coBection go together so weB. They do so, because the concentration of solar energy does not demand imaging qualities, but instead requires flexible designs of highly uniform flux concentrators coping with solar disk size, solar spectrum, and tracking errors. Nonimaging optics has been developed to perfection since its discovery in 1965, in dealing with solar power conversion. Much of this experience is useful in nonimaging optical design in other fields where the markets already are more rewarding than in solar power generation, such as optoelectronics.

Executive Summary.- 1 Lenses and Mirrors for Solar Energy.- 1.1 Photovoltaic or Thermal Concentration?.- 1.2 Classification of Solar Concentrators.- 2 Nonimaging Optics.- 2.1 Nonimaging Concentration.- 2.2 Generalized Ideal Concentration.- 2.3 Lagrange Invariant.- 2.4 Nonimaging Mirrors.- 3 Fresnel Lens Optics.- 3.1 Reflection and Refraction.- 3.2 Total Internal Reflection.- 3.3 Deviation.- 3.4 Refractive Indices.- 3.5 Minimum Dispersion.- 4 Earlier Fresnel Lenses.- 4.1 History of Fresnel Lenses.- 4.2 Recent Developments.- 4.3 Simple Fresnel Lenses.- 4.4 Domed or Arched Fresnel Lenses.- 5 Nonimaging Fresnel Lens Design.- 5.1 Applied Nonimaging Lens Design.- 5.2 The Optimum Linear Lens.- 5.3 Rotational Symmetry.- 5.4 Arbitrary Shapes.- 5.5 Diverger Lens for Lighting.- 6 Lens Evaluation.- 6.1 Losses.- 6.2 Transmittance.- 6.3 Geometrical Losses.- 6.4 Concentration Ratios.- 6.5 Nonideal Concentration.- 7 Optimization of Stationary Concentrators.- 7.1 Choice of Stationary Collector.- 7.2 Solar Radiation Model.- 7.3 Radiation on a Tilted Plane.- 7.4 Acceptance by a Solar Concentrator.- 7.5 Compound Parabolic Concentrators.- 7.6 Quasi-3D Concentrators.- 8 Prototype Design, Manufacturing, and Testing.- 8.1 Prototypes of Choice.- 8.2 Prism Size.- 8.3 Lens Redesign.- 8.4 Lens Manufacturing.- 8.5 Sample.- 8.6 Preliminary Tests.- 8.7 Partial Absorber Illumination.- 8.8 Tracking.- 9 Concentrated Sunlight and Photovoltaic Conversion.- 9.1 Flux Density.- 9.2 Solar Disk Size and Brightness.- 9.3 Spectral Color Dispersion.- 9.4 Concentrator Cells.- 9.5 Multijunction Devices.- 9.6 Photovoltaic System Performance.- 9.7 Concentration and Cost.- 10 Solar Thermal Concentrator Systems.- 10.1 Solar Resources.- 10.2 Solar Sorption Air Conditioning.- 10.3 Energy and Exergy.- 10.4 Exergy of a Concentrating Collector.- 11 Solar Concentration in Space.- 11.1 Space Concentrator Arrays.- 11.2 Design Challenges in Space.- 11.3 Lenses and Mirrors!.- References.

Erscheint lt. Verlag	31.7.2001
Reihe/Serie	Springer Series in Optical Sciences
Zusatzinfo	XI, 274 p.
Verlagsort	Berlin
Sprache	englisch
Maße	156 x 234 mm
Gewicht	524 g
Themenwelt	Naturwissenschaften ► Physik / Astronomie ► Optik
	Technik ► Elektrotechnik / Energietechnik
	Technik ► Maschinenbau
Schlagworte	Dispersion • Fresnel lens • Fresnel-Linse • geometric optics • optical design • Optics • Prism • solar collector • Total internal reflection • Tracking
ISBN-10	3-540-41841-5 / 3540418415
ISBN-13	978-3-540-41841-2 / 9783540418412
Zustand	Neuware
