Mechanics of Paper Products (eBook)

Kaarlo Niskanen (Herausgeber)

eBook Download: PDF

2012
271 Seiten
De Gruyter (Verlag)
978-3-11-025463-1 (ISBN)

Infos

This graduate level textbook focuses on the mechanical properties and performance of products made of fiber-based materials such as paper and board. The book aims to help students develop effective skills for solving problems of product performance and engineering challenges in new product development. Therefore the material is organized with a problem-based approach - a practical example of product performance is presented and then the relevant mechanics are analyzed to deduce which material properties control the performance.

Kaarlo Niskanen, Mid Sweden University, Sundsvall, Sweden.

Autor
