Surface Acoustic Wave Filters (eBook)

With Applications to Electronic Communications and Signal Processing

David Morgan (Autor)

eBook Download: PDF

2010 | 2. Auflage
448 Seiten
Elsevier Science (Verlag)
978-0-08-055013-8 (ISBN)

Infos

This book gives the fundamental principles and device design techniques for surface acoustic wave filters. It covers the devices in widespread use today: bandpass and pulse compression filters, correlators and non-linear convolvers and resonators. The newest technologies for low bandpass filters are fully covered such as unidirectional transducers, resonators in impedance element filters, resonators in double-mode surface acoustic wave filters and transverse-coupled resonators using waveguides.

The book covers the theory of acoustic wave physics, the piezoelectric effect, electrostatics at a surface, effective permittivity, piezoelectric SAW excitation and reception, and the SAW element factor. These are the main requirements for developing quasi-static theory, which gives a basis for the non-reflective transducers in transversal bandpass filters and interdigital pulse compression filters. It is also needed for the reflective transducers used in the newer devices.

* A thorough revision of a classic on surface acoustic wave filters first published in 1985 and still in print
* Uniquely combines easy -to -understand principles with practical design techniques for all the devices in widespread use today
* Complete coverage of all the latest devices which are key to mobile phones, TVs and radar systems
* Includes a new foreword by Sir Eric Albert Ash

---

Surface Acoustic Wave Filters gives the fundamental principles and device design techniques for surface acoustic wave filters. It covers the devices in widespread use today: bandpass and pulse compression filters, correlators and non-linear convolvers and resonators. The newest technologies for low bandpass filters are fully covered such as unidirectional transducers, resonators in impedance element filters, resonators in double-mode surface acoustic wave filters and transverse-coupled resonators using waveguides. The book covers the theory of acoustic wave physics, the piezoelectric effect, electrostatics at a surface, effective permittivity, piezoelectric SAW excitation and reception, and the SAW element factor. These are the main requirements for developing quasi-static theory, which gives a basis for the non-reflective transducers in transversal bandpass filters and interdigital pulse compression filters. It is also needed for the reflective transducers used in the newer devices. - A thorough revision of a classic on surface acoustic wave filters first published in 1985 and still in print- Uniquely combines easy-to-understand principles with practical design techniques for all the devices in widespread use today- Complete coverage of all the latest devices which are key to mobile phones, TVs and radar systems- Includes a new foreword by Sir Eric Albert Ash
