Fundamentals of Geometry Construction
Springer International Publishing (Verlag)
978-3-030-43130-3 (ISBN)
The textbook provides both beginner and experienced CAD users with the math behind the CAD. The geometry tools introduced here help the reader exploit commercial CAD software to its fullest extent. In fact, the book enables the reader to go beyond what CAD software packages offer in their menus.
Chapter 1 summarizes the basic Linear and Vector Algebra pertinent to vectors in 3D, with some novelties: the 2D form of the vector product and the manipulation of "larger" matrices and vectors by means of block-partitioning of larger arrays. In chapter 2 the relations among points, lines and curves in the plane are revised accordingly; the difference between curves representing functions and their geometric counterparts is emphasized. Geometric objects in 3D, namely, points, planes, lines and surfaces are the subject of chapter 3; of the latter, only quadrics are studied, to keep the discussion at an elementary level, but the interested reader is guided to the literature on splines.The concept of affine transformations, at the core of CAD software, is introduced in chapter 4, which includes applications of these transformations to the synthesis of curves and surfaces that would be extremely cumbersome to produce otherwise.
The book, catering to various disciplines such as engineering, graphic design, animation and architecture, is kept discipline-independent, while including examples of interest to the various disciplines. Furthermore, the book can be an invaluable complement to undergraduate lectures on CAD.Jorge Angeles is professor at the Department of Mechanical Engineering and at the Centre for Intelligent Machines at McGill University, Montreal, Canada.
Introduction to Geometry Construction.- 2D Objects.- 3D Objects.- Affine Transformations.
"The book serves as a timely and relevant body of concepts and mathematical fundamentals behind the computer aided design (CAD) technology. ... The presentation of the material is formal, precise and convincing. Overall, the book is a useful reference and textbook material to a broad community users of CAD tools who wish to gain underlying mathematical knowledge." (Witold Pedrycz, zbMATH 1458.51001, 2021)
| Erscheinungsdatum | 23.04.2020 |
|---|---|
| Reihe/Serie | Springer Tracts in Mechanical Engineering |
| Zusatzinfo | XX, 168 p. 109 illus., 49 illus. in color. |
| Verlagsort | Cham |
| Sprache | englisch |
| Maße | 155 x 235 mm |
| Gewicht | 453 g |
| Themenwelt | Informatik ► Weitere Themen ► CAD-Programme |
| Mathematik / Informatik ► Mathematik ► Geometrie / Topologie | |
| Technik ► Maschinenbau | |
| Schlagworte | 3D objects • affine transformations • CAD Software • Engineering design • Geometric Objects • linear algebra • Vector Algebra |
| ISBN-10 | 3-030-43130-4 / 3030431304 |
| ISBN-13 | 978-3-030-43130-3 / 9783030431303 |
| Zustand | Neuware |
