VHDL Answers to Frequently Asked Questions

Ben Cohen (Autor)

Buch | Softcover

384 Seiten

2012 | 2nd ed. 1998. Softcover reprint of the original 2nd ed. 1998
Springer-Verlag New York Inc.
978-1-4613-7581-4 (ISBN)

Artikel merken

VHDL Answers to Frequently asked Questions is a follow-up to the author's book VHDL Coding Styles and Methodologies (ISBN 0-7923-9598-0). On completion of his first book, the author continued teaching VHDL and actively participated in the comp. lang. vhdl newsgroup. During his experiences, he was enlightened by the many interesting issues and questions relating to VHDL and synthesis. These pertained to: misinterpretations in the use of the language; methods for writing error free, and simulation efficient, code for testbench designs and for synthesis; and general principles and guidelines for design verification. As a result of this wealth of public knowledge contributed by a large VHDL community, the author decided to act as a facilitator of this information by collecting different classes of VHDL issues, and by elaborating on these topics through complete simulatable examples. TItis book is intended for those who are seeking an enhanced proficiency in VHDL. Its target audience includes: 1. Engineers. The book addresses a set of problems commonly experienced by real users of VHDL. It provides practical explanations to the questions, and suggests practical solutions to the raised issues. It also includes packages of common utilities that are useful in the generation of debug code and testbench designs. These packages include conversions to strings (the IMAGE package), generation of Linear Feedback Shift Registers (LFSR), Multiple Input Shift Register (MISR), and random number generators.

1. Language Elements.- 1.1 Why VHDL for Digital Designs.- 1.2 Salient Points of Concurrent Statements.- 1.3 Guarded Signal Assignments.- 1.4 Signals and Ports.- 1.5 Configurations.- 1.6 Arithmetic Issues and Operators.- 1.7 PACKAGE STD_LOGIC_1164.- 1.8 Range Constraint in Type Definition.- 1.9 Shared Variables.- 2. Arrays.- 2.1 Array Structure Representations.- 2.2 Arrays — Legal Operations.- 2.3 Array Slices and Ranges.- 2.4 Array Initialization.- 2.5 Constant Arrays in Case.- 2.6 Constrained and Unconstrained Arrays.- 2.7 Mapping Arrays of Different Sizes.- 2.8 Unconstrained Aggregate with “Others ”.- 2.9 Illegal Array Types.- 3. Drivers.- 3.1 Multiple Drivers — Case 1.- 3.2 Multiple Drivers — Case 2.- 3.3 Multiple Drivers Error — Case 3.- 3.4 Multiple Drivers Error — Component.- 3.5 Coding Style for Detection of Multiple Drivers.- 4. Subprograms.- 4.1 Side Effects From A Procedure.- 4.2 Garbage Collection of Dynamically Created Objects.- 4.3 Acceptable Types in Parameter Lists for Function Calls.- 4.4 Files Declarations in Procedures.- 4.5 Multiple Accesses of Same File.- 4.6 File Array.- 4.7 Conversion Function From Integer To Time.- 4.8 Normalization In Subprograms.- 5. Packages.- 5.1 Converting Typed Objects To Strings.- 5.2 Printing Objects From Vhdl.- 5.3 Multiple Input Signature Register (Misr).- 5.4 Design of a Linear Feedback Shift Register (Lfsr).- 5.5 Random Number Generation.- 5.6 Deferred Constant in Package Declaration.- 5.7 Complex Numbers and Overloaded Operators.- 5.8 Ieee Standards.- 6. Models.- 6.1 Large Ram Model For Simulation..- 6.2 Zero Ohm Resistor (Wire, Bridge) Model.- 6.3 Error Injector Model.- 6.4 Transfer Gate (Switch).- 7. Synthesis.- 7.1 Supported/Unsupported Constructs for Synthesis.- 7.2 Synthesis Sensitivity Rules.- 7.3Latch/Register/Combinational Logic.- 7.4 Latch Inferrance in Functions.- 7.5 Variable Initialization and Lifetime.- 7.6 Wait Statement.- 7.7 Defining Shift Registers in Synthesis.- 7.8 Register File.- 7.9 Multiplexer Model.- 7.10 Demultiplexer Model.- 7.11 Barrel Shifter.- 7.12 Use of “don’t Care” in Case Statement.- 7.13 Parameterized Priority Encoder.- 7.14 Generating A Synchronous Precharge.- 7.15 Technology and Vhdl Code Design.- 7.16 Synthesizing Tri-States.- 7.17 Subelement Association.- 7.18 Finite State Machine (Fsm).- 7.19 One-Hot Encoding.- 7.20 Instantiating Synopsys® Designware Components.- 7.21 Resource Sharing.- 7.22 Applying Digital Design Experiences.- 7.23 Address Range Identification Via Inferred Comparator.- 7.24 Port Mapping to Ground Or Vcc.- 7.25 Bit Reversal.- 7.26 How to Design a Timer in Vhdl.- 7.27 Specifying a Multiplier.- 7.28 Behavioral Synthesis.- 8. Design Verification and Testbench.- 8.1 Verification Processes.- 8.2 Functional Verification.- 8.3 Regression Tests.- 8.4 Formal Verification.- 8.5 Bus Functional Model (Bfm) Modeling.- 8.6 Application of Misr, Random, Lfsr Packages for Auto-Regression.- 8.7 Strength Stripper.- 9. Potpourri.- 9.1 Methods To Enhance Simulation Speed.- 9.2 Accessing Signals Internal to Components.- 9.3 Transferring a Line Onto a Signal.- 9.4 Type Declaration in Multiple Packages.- 9.5 Internet - Frequently Asked Questions.- 9.6 Vhdl Text Editor?.- 9.7 Vital.- 9.8 Behavioral Modeling.- 9.9 Final Vhdl Exam.- 10. Design for Reuse.- 10.1 Design Processes for Reusability.- 10.2 Parameterized, Reusable and Readable Code.- 10.3 Documentation of Vhdl Designs.- Appendix A: Vhdl’93 and Vhdl’87 Syntax Summary.- Appendix B: Package Standard.- Appendix C: Package Textio.- Appendix D: Package Std_Logic_1164.-Appendix E: Package Std_Logic_Arith.- Appendix F: Vhdl Predefined Attributes.

Erscheint lt. Verlag	8.10.2012
Zusatzinfo	XXIX, 384 p.
Verlagsort	New York, NY
Sprache	englisch
Maße	178 x 254 mm
Themenwelt	Informatik ► Weitere Themen ► CAD-Programme
	Informatik ► Weitere Themen ► Hardware
	Technik ► Elektrotechnik / Energietechnik
ISBN-10	1-4613-7581-9 / 1461375819
ISBN-13	978-1-4613-7581-4 / 9781461375814
Zustand	Neuware
