Higher Order Basis Based Integral Equation Solver (HOBBIES) - Yunong Zhang, Tapan K. Sarkar, Xunwang Zhao, Daniel Garcia-Donoro, Weixin Zhao

Higher Order Basis Based Integral Equation Solver (HOBBIES)

Buch | Hardcover
568 Seiten
2012
John Wiley & Sons Inc (Verlag)
978-1-118-14065-9 (ISBN)
CHF 339,95 inkl. MwSt
  • Versand in 10-15 Tagen
  • Versandkostenfrei
  • Auch auf Rechnung
  • Artikel merken
This book offers the latest in the parallel solution of integral equations for both in-core and out-of-core modes. User-friendly computer code is provided, with a strong and unique capability for solving challenging electromagnetic field problems consisting of complex material structures.
The latest in parallel EM solutions with both in-core and out-of-core solvers

The solution of complex electromagnetic (EM) problems requires one to address the issues related with numerical accuracy and efficient distribution of the solution procedure over multiple computational nodes. With the advent of multicore processors and high performance computing (HPC) technology, the EM software designers need to know how to add new functionality to computational EM codes so that they can run efficiently on these new processors.

Higher Order Basis Based Integral Equation Solver [HOBBIES] presents a road map for the analysis of complex material structures using the high-performance parallel simulation software known as HOBBIES. Focusing on the Method of Moments (MoM), the book features new parallel programming techniques and user-friendly code with superior capabilities for solving challenging EM radiation and scattering problems. It provides readers with complete guidance on how to extend the capability of MoM and achieve faster and more accurate EM analysis and utilize multicore CPUs on desktop computers. Complete with an academic version of the HOBBIES software, this book:



Explains the unique features of the higher order basis functions in the solution of integral equations in a MoM context
Shows how to generate a properly load balanced parallel computational procedure for MoM matrix filling and matrix equation solving in both in-core and out-of-core implementation
Presents a professional graphical users interface (GUI) for generating the geometrical structure based on NURBS modeling
Illustrates various automatic meshing procedures based on an a-priori defined error between the actual geometry and the meshed structure
Outlines all the key features of the HOBBIES software, including multiple optimization procedures for EM synthesis

The bottleneck of traditional MoM arises from the lack of memory in computers for solution of large problems. This is mitigated by using higher order basis functions and out-of-core solver in HOBBIES. HOBBIES has the capability to perform numerically accurate EM simulations using thousands of CPU cores in an HPC environment using a properly load balanced out-of-core solver. In this way, it provides a cost-effective choice for addressing modern engineering and scientific challenges that arise from the extremely complicated real-life applications.

YU ZHANG, PhD, is a professor in the School of Electronic Engineering at Xidian University in Xi'an, China. TAPAN K. SARKAR, PhD, is a professor in the Department of Electrical Engineering and Computer Science at Syracuse University, New York, USA. XUNWANG ZHAO, PhD, is an associate professor in the School of Electronic Engineering at Xidian University, Xi'an, China. DANIEL GARCIA-DOÑORO is a PhD student in the Department of Signal Theory and Communications at Universidad Carlos III de Madrid in Madrid, Spain. WEIXIN ZHAO is a PhD student in the Department of Electrical Engineering and Computer Science at Syracuse University, New York, USA. MAGDALENA SALAZAR-PALMA, PhD, is a professor in the Department of Signal Theory and Communications at Universidad Carlos III de Madrid, Spain. SIOWENG TING, PhD, is an assistant professor in the Department of Electrical and Computer Engineering at the University of Macau, China.
