In addition to its thorough coverage of DSP design and programming techniques, Smith also covers the operation and usage of DSP chips. He uses Analog Devices' popular DSP chip family as design examples. Also included on the companion website is technical info on DSP processors from the four major manufacturers (Analog Devices, Texas Instruments, Motorola, and Lucent) and other DSP software.
*Covers all major DSP topics
*Full of insider information and shortcuts
*Basic techniques and algorithms explained without complex numbers

---

In addition to its thorough coverage of DSP design and programming techniques, Smith also covers the operation and usage of DSP chips. He uses Analog Devices' popular DSP chip family as design examples. - Covers all major DSP topics- Full of insider information and shortcuts- Basic techniques and algorithms explained without complex numbers

Textauszug

CHAPTER 2

Statistics, Probability and Noise

Statistics and probability are used in digital signal processing to characterize signals and the processes that generate them. For example, a primary use of DSP is to reduce interference, noise, and other undesirable components in acquired data. These may be an inherent part of the signal being measured, arise from imperfections in the data acquisition system, or be introduced as an unavoidable byproduct of some DSP operation. Statistics and probability allow these disruptive features to be measured and classified, the first step in developing strategies to remove the offending components. This chapter introduces the most important concepts in statistics and probability, with emphasis on how they apply to acquired signals.

Signal and Graph Terminology

A signal is a description of how one parameter is related to another parameter. For example, the most common type of signal in analog electronics is a voltage that varies with time. Since both parameters can assume a continuous range of values, we will call this a continuous signal. In comparison, passing this signal through an analog-to-digital converter forces each of the two parameters to be quantized. For instance, imagine the conversion being done with 12 bits at a sampling rate of 1000 samples per second. The voltage is curtailed to 4096 (212) possible binary levels, and the time is only defined at one millisecond increments. Signals formed from parameters that are quantized in this manner are said to be discrete signals or digitized signals. For the most part, continuous signals exist in nature, while discrete signals exist inside computers (although you can find exceptions to both cases). It is also possible to have signals where one parameter is continuous and the other is discrete. Since these mixed signals are quite uncommon, they do not have special names given to them, and the nature of the two parameters must be explicitly stated.

Figure 2-1 shows two discrete signals, such as might be acquired with a digital data acquisition system. The vertical axis may represent voltage, light intensity, sound pressure, or an infinite number of other parameters. Since we don’t know what it represents in this particular case, we will give it the generic label: amplitude. This parameter is also called several other names: the y-axis, the dependent variable, the range, and the ordinate.

FIGURE 2-1 Examples of two digitized signals with different means and standard deviations.

The horizontal axis represents the other parameter of the signal, going by such names as: the x-axis, the independent variable, the domain, and the abscissa. Time is the most common parameter to appear on the horizontal axis of acquired signals; however, other parameters are used in specific applications. For example, a geophysicist might acquire measurements of rock density at equally spaced distances along the surface of the earth. To keep things general, we will simply label the horizontal axis: sample number. If this were a continuous signal, another label would have to be used, such as: time, distance, x, etc.

The two parameters that form a signal are generally not interchangeable. The parameter on the y-axis (the dependent variable) is said to be a function of the parameter on the x-axis (the independent variable). In other words, the independent variable describes how or when each sample is taken, while the dependent variable is the actual measurement. Given a specific value on the x-axis, we can always find the corresponding value on the y-axis, but usually not the other way around.

Pay particular attention to the word domain, a very widely used term in DSP. For instance, a signal that uses time as the independent variable (i.e., the parameter on the horizontal axis), is said to be in the time domain. Another common signal in DSP uses frequency as the independent variable, resulting in the term, frequency domain. Likewise, signals that use distance as the independent parameter are said to be in the spatial domain (distance is a measure of space). The type of parameter on the horizontal axis is the domain of the signal; it’s that simple. What if the x-axis is labeled with something very generic, such as sample number? Authors commonly refer to these signals as being in the time domain. This is because sampling at equal intervals of time is the most common way of obtaining signals, and they don’t have anything more specific to call it.

Although the signals in Fig. 2-1 are discrete, they are displayed in this figure as continuous lines. This is because there are too many samples to be distinguishable if they were displayed as individual markers. In graphs that portray shorter signals, say less than 100 samples, the individual markers are usually shown. Continuous lines may or may not be drawn to connect the markers, depending on how the author wants you to view the data. For instance, a continuous line could imply what is happening between samples, or simply be an aid to help the reader’s eye follow a trend in noisy data. The point is, examine the labeling of the horizontal axis to find if you are working with a discrete or continuous signal. Don’t rely on an illustrator’s ability to draw dots.

The variable, N, is widely used in DSP to represent the total number of samples in a signal. For example, N = 512 for the signals in Fig. 2-1. To keep the data organized, each sample is assigned a sample number or index. These are the numbers that appear along the horizontal axis. Two notations for assigning sample numbers are commonly used. In the first notation, the sample indexes run from 1 to N (e.g., 1 to 512). In the second notation, the sample indexes run from 0 to N−1 (e.g., 0 to 511). Mathematicians often use the first method (1 to N), while those in DSP commonly use the second (0 to N−1). In this book, we will use the second notation. Don’t dismiss this as a trivial problem. It will confuse you sometime during your career. Look out for it!

Mean and Standard Deviation

The mean, indicated by μ (a lower-case Greek mu), is the statistician’s jargon for the average value of a signal. It is found just as you would expect: add all of the samples together, and divide by N. It looks like this in mathematical form:

EQUATION 2-1

Calculation of a signal’s mean. The signal is contained in x0 through xN−1, i is an index that runs through these values, and μ is the mean.

In words, sum the values in the signal, xi, by letting the index, i, run from 0 to N−1. Then finish the calculation by dividing the sum by N. This is identical to the equation: μ = (x0 + x1 + x2 + . + xN−1)/N. If you are not already familiar with Σ (upper-case Greek sigma) being used to indicate summation, study these equations carefully, and compare them with the computer program in Table 2-1. Summations of this type are abundant in DSP, and you need to understand this notation fully.

TABLE 2-1

In electronics, the mean is commonly called the DC (direct current) value. Likewise, AC (alternating current) refers to how the signal fluctuates around the mean value. If the signal is a simple repetitive waveform, such as a sine or square wave, its excursions can be described by its peak-to-peak amplitude. Unfortunately, most acquired signals do not show a well defined peak-to-peak value, but have a random nature, such as the signals in Fig. 2-1. A more generalized method must be used in these cases, called the standard deviation, denoted by σ (a lower-case Greek sigma).

As a starting point, the expression, |xi − μ|, describes how far the ith sample deviates (differs) from the mean. The average deviation of a signal is found by summing the deviations of all the individual samples, and then dividing by the number of samples, N. Notice that we take the absolute value of each deviation before the summation; otherwise the positive and negative terms would average to zero. The average deviation provides a single number representing the typical distance that the samples are from the mean. While convenient and straightforward, the average deviation is almost never used in statistics. This is because it doesn’t fit well with the physics of how signals operate. In most cases, the important parameter is not the deviation from the mean, but the power represented by the deviation from the mean. For example, when random noise signals combine in an electronic circuit, the...
