2D Materials for Nanoelectronics
CRC Press (Verlag)
978-0-367-78303-7 (ISBN)
Comprised of chapters authored by internationally recognised researchers, this book:
- Discusses the use of graphene for high-frequency analog circuits
- Explores logic and photonic applications of molybdenum disulfide (MoS2)
- Addresses novel 2D materials including silicene, germanene, stanene, and phosphorene
- Considers the use of 2D materials for both field-effect transistors (FETs) and logic circuits
- Provides background on the simulation of structural, electronic, and transport properties from first principles
2D Materials for Nanoelectronics presents extensive, state-of-the-art coverage of the fundamental and applied aspects of this exciting field.
Michel Houssa earned his master's and PhD in physics at the University of Liege, Belgium. He is presently a professor in the Department of Physics and Astronomy at the University of Leuven, Belgium. His current research focuses on the first principles modeling of various materials, including semiconductor/oxide interfaces and two-dimensional materials (silicene, germanene, and transition metal dichalcogenides), and their heterostructures. He has authored or co-authored nearly 350 publications, given about 50 invited talks and seminars, and been co-organiser of several international symposia and conferences. He is an Electrochemical Society fellow and an Institute of Electrical and Electronics Engineers senior member. Athanasios Dimoulas earned his PhD in applied physics at the University of Crete, Greece. He is currently the research director and head of the Epitaxy and Surface Science Laboratory at the National Center for Scientific Research "Demokritos," Athens, Greece. He has coordinated several European-funded projects in advanced CMOS and received the European Research Council-funded SMARTGATE - "Smart Gates for the 'Green' Transistor" Advanced Investigator Grant 2011 - "IDEAS." Widely published, Dr. Dimoulas has about 40 invited talks and has been active with several symposia, conferences, and committees as an organizer and chair. He has held fellowships at the University of Groningen, Holland; California Institute of Technology, Pasadena, USA; and University of Maryland, College Park, USA; and been a visiting research scientist at IBM Zurich Research Laboratory, Switzerland. Alessandro Molle earned his PhD in materials science at the University of Genoa, Italy. He is presently a research scientist and group leader of the research line on low-dimensional materials and devices in the MDM Laboratory at the Consiglio Nazionale delle Ricerche-Istituto per la Microelettronica e Microsistemi (CNR-IMM), Agrate Brianza, Italy. He is currently involved in the integration of silicene and other 2D elementary materials into transistors, and in the synthesis and structural characterisation of 2D materials beyond graphene. Widely published, he has been active with symposia, received many invitations to present at international conferences, and guest edited special issues of proceeding papers. He has been co-chairing a master's course on surfaces and interfaces at the University of Milano-Bicocca, Italy.
Theory of the Structural, Electronic, and Transport Properties of Graphene
Epitaxial Graphene: Progress on Synthesis and Device Integration
Metal Contacts to Graphene
Graphene for RF Analogue Applications
High-Field and Thermal Transport in Graphene
Theoretical Study of Transition Metal Dichalcogenides
Physico-Chemical Characterisation of MoS2/Metal and MoS2/Oxide Interfaces
Transition Metal Dichalcogenide Schottky Barrier Transistors: A Device Analysis and Material Comparison
TMD-Based Photodetectors, Light Emitters, and Photovoltaics
Optoelectronics, Mechanical Properties, and Strain Engineering in MoS2
Device Physics and Device Mechanics for Flexible TMD and Phosphorene Thin-Film Transistors
Structural, Electronic, and Transport Properties of Silicene and Germanene
Group IV Semiconductor 2D Materials: The Case of Silicene and Germanene
Stanene: A Likely 2D Topological Insulator
Phosphorene: A Novel 2D Material for Future Nanoelectronics and Optoelectronics
2D Crystal-Based Heterostructures for Nanoelectronics
| Erscheinungsdatum | 06.04.2021 |
|---|---|
| Reihe/Serie | Series in Materials Science and Engineering |
| Verlagsort | London |
| Sprache | englisch |
| Maße | 156 x 234 mm |
| Gewicht | 894 g |
| Themenwelt | Naturwissenschaften ► Biologie |
| Naturwissenschaften ► Physik / Astronomie ► Optik | |
| Technik ► Elektrotechnik / Energietechnik | |
| Technik ► Maschinenbau | |
| Technik ► Umwelttechnik / Biotechnologie | |
| ISBN-10 | 0-367-78303-7 / 0367783037 |
| ISBN-13 | 978-0-367-78303-7 / 9780367783037 |
| Zustand | Neuware |
