Process Control
John Wiley & Sons Inc (Verlag)
978-1-119-15774-8 (ISBN)
This expanded new edition is specifically designed to meet the needs of the process industry, and closes the gap between theory and practice.
Back-to-basics approach, with a focus on techniques that have an immediate practical application, and heavy maths relegated to the end of the book
Written by an experienced practitioner, highly regarded by major corporations, with 25 years of teaching industry courses
Supports the increasing expectations for Universities to teach more practical process control (supported by IChemE)
Myke King is Director of Whitehouse Consulting which provides process control consulting and training services. He has been running courses for industry covering all aspects of process control for the past 30 years (over 150 courses to over 1,500 delegates). Myke graduated from Cambridge University in 1974 with a master’s degree in Chemical Engineering. After University he joined Exxon to work as control engineer in their oil refinery in the UK, later managing the process control section. In 1983 he co-founded the consulting company KBC Process Automation, which was later sold to Honeywell. He thus has about 40 years of relevant experience - working in over 30 countries providing services to over 100 companies.
