Coplanar Waveguide Circuits, Components, and Systems

Rainee N. Simons (Autor)

Buch | Hardcover

464 Seiten

2001
Wiley-IEEE Press (Verlag)
978-0-471-16121-9 (ISBN)

Artikel merken

Up-to-date coverage of the analysis and applications of coplanar waveguides to microwave circuits and antennas The unique feature of coplanar waveguides, as opposed to more conventional waveguides, is their uniplanar construction, in which all of the conductors are aligned on the same side of the substrate. This feature simplifies manufacturing and allows faster and less expensive characterization using on-wafer techniques.

Coplanar Waveguide Circuits, Components, and Systems is an engineer's complete resource, collecting all of the available data on the subject. Rainee Simons thoroughly discusses propagation parameters for conventional coplanar waveguides and includes valuable details such as the derivation of the fundamental equations, physical explanations, and numerical examples.

Coverage also includes:

Discontinuities and circuit elements
Transitions to other transmission media
Directional couplers, hybrids, and magic T
Microelectromechanical systems based switches and phase shifters
Tunable devices using ferroelectric materials
Photonic bandgap structures
Printed circuit antennas

RAINEE N. SIMONS, PhD, works in the Communications Technology Division at the National Aeronautics and Space Administration's Glenn Research Center in Cleveland, Ohio, and is a fellow of IEEE.

Preface.

Introduction.

Conventional Coplanar Waveguide.

Conductor-Backed Coplanar Waveguide.

Coplanar Waveguide with Finite-Width Ground Planes.

Coplanar Waveguide Suspended Inside A Conducting Enclosure.

Coplanar Striplines.

Microshield Lines and Coupled Coplanar Waveguide.

Attenuation Characteristics of Conventional, Micromachined, and Superconducting Coplanar Waveguides.

Coplanar Waveguide Discontinuities and Circuit Elements.

Coplanar Waveguide Transitions.

Directional Couplers, Hybrids, and Magic-Ts.

Coplanar Waveguide Applications.

References.

Index.

Erscheint lt. Verlag	20.4.2001
Reihe/Serie	Wiley Series in Microwave and Optical Engineering
Sprache	englisch
Maße	161 x 237 mm
Gewicht	860 g
Themenwelt	Naturwissenschaften ► Physik / Astronomie ► Mechanik
Themenwelt	Technik ► Elektrotechnik / Energietechnik
ISBN-10	0-471-16121-7 / 0471161217
ISBN-13	978-0-471-16121-9 / 9780471161219
Zustand	Neuware
